C.ALARMS APPENDIX B-64254EN/02
- 190 -
C.1 ALARMS COMMON TO ALL CYCLES
Alarm
number
Message Cause Countermeasure
3010 NO MACHINING CYCLE BLOCK. The selected cycle number does
not contain any cutting cycle.
Please select a cycle number
containing a machining block.
3050 WRONG FEED RATE The cutting feedrate speed is blank
or zero in the Set screen and in
COND tab of the cycle causing the
alarm.
Please specify a value on the
feedrate set screen, or specify
the value of the cutting
feedrate in the COND tab of
the cycle causing the alarm.
3101 WRONG TOOL POSITION. The position of the tool when Cycle
Start is pressed is not compatible
with the cutting motion of the cycle
being executed.
The current tool position may
cause a crash.
Please move the tool to an
appropriate position before
pressing cycle start again.
The tool shall be placed on a
point not causing a crash after
cycle start is pressed.
C.2 TAPER, STANDARD/FACE CORNER, RADIUS, FREE
FIGURE, AND FACE
Alarm
number
Message Cause Countermeasure
3006 WRONG CUTTING AREA The cutting area has been not
correctly specified because the
finish amount values are too large
and/or the corner radius value or
chamfering values are too large.
Please review the values
specified for finishing amount,
corner radius and chamfering.
3014 WRONG FIGURE DATA For an external cutting the
specified figure does not follows
an increasing monotonously
shape along the X axis. For an
internal cutting cycle the specified
figure does not follows a
decreasing monotonously shape
along the X axis.
Please modify the shape
according the following cases:
In external cutting cycle the
figure shall be increasing
monotonously along the X axis.
In internal cutting cycle the figure
shall be decreasing
monotonously along the X axis.
