TURN MATE i Operators manual Page 190

Operators manual
B.PARAMETERS APPENDIX B-64254EN/02
- 178 -
#7 #6 #5 #4 #3 #2 #1 #0
9101 G62 FSP PWD
PWD 0 : When the power is turned on, the system is not switched to the
TURN MATE i screen.
1 : When the power is turned on, the system is switched to the
TURN MATE i screen.
FSP 0 : A FANUC spindle is used.
1 : A FANUC spindle is not used.
G62 0 : To display TURN MATE i it is not required to set PMC signal
G62.4
1 : To display TURN MATE i it is required to set PMC signal G62.4
#7 #6 #5 #4 #3 #2 #1 #0
9102 TDP GER LMT LDM SLM CND
CND 0 : Tab COND in cycle data input screen is displayed.
1 : Tab COND in cycle data input screen is not displayed.
SLM 0 : The spindle load meter is displayed on the Base Screen.
1 : The spindle load meter is not displayed on the Base Screen.
LDM 0 : The servo load meter is displayed on the Base Screen.
1 : The servo load meter is not displayed on the Base Screen.
LMT 0 : The “LIMIT" button is displayed on the Base Screen.
1 : The “LIMIT" button is not displayed on the Base Screen.
GER 0 : It is possible to set the gear number of the spindle.
1 : It is not possible to set the gear number of the spindle.
TDP 0 : The tool selection screen is available
1 : The tool selection screen is not available.
#7 #6 #5 #4 #3 #2 #1 #0
9103 SFA
SFA 0 : Spindle rotation direction It is considered clockwise if PMC
signals G070#5(SFRA)=1 && G070#4(SRVA)=0.
Spindle rotation direction It is considered counter clockwise if
PMC signals G070#5(SFRA)=0 && G070#4(SRVA)=1.
1 : Spindle rotation direction It is considered clockwise if PMC
signals G070#5(SFRA)=0 && G070#4(SRVA)=1.
Spindle rotation direction It is considered counter clockwise if
PMC signals G070#5(SFRA)=1 && G070#4(SRVA)=0.
#7 #6 #5 #4 #3 #2 #1 #0
9104 BN2 BN1
BN2 BN1 Maximum contour block number
0 0 10
0 1 15
1 0 30
