4.16i/18i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04

- -126

4.1.8 Buffer Mode Specifications

The buffer mode is designed to handle NC programs larger than the

capacity of the data server board built-in hard disk. In this mode, the

data server board built-in hard disk is used as a temporary, intermediate

buffer.

In the buffer mode, two areas (A and B) are previously prepared on the

hard disk. While an NC program is being supplied from one (A) of the

areas to the CNC, the rest of the NC program is read from the host

computer into the other area (B), using the FTP. When the data transfer

from area A ends, a data transfer from area B to the CNC is started, and

the NC program transfer from the host computer to the emptied area

(A) is resumed, using the FTP.

Repeating this sequence enables an NC program larger than the

capacity of the data server board built-in hard disk to be handled.

Using the buffer mode, however, requires that the NC program be

previously divided into several files in the host computer.

The size of resulting smaller files must not be larger than half the

remaining capacity of the data server board built-in hard disk. If the

file size is very large (for example, not smaller than 100 MB), it will

take a fairly long time to read the first file from the host computer, thus

delaying the start of the operation.

NOTE

The Series 21i-A/B cannot use the buffer mode.
