Ethernet/Data Server Board Operators manual Page 211

Operators manual
B-63354EN/04 IV. OPERATION 4.16i/18i DATA SERVER FUNCTIONS
- -197
4.11.3 Switching Data Server Modes
Switch data server modes.
Procedure
1 Press function key
SYSTEM
.
2 Press the continuation menu key at the right end of the soft key
menu.
3 When you press soft key [DS-MIN], the Maintenance of Data
Server screen appears.
For the Series 16i/18i/21i-B, to display the Ethernet Error
Message screen, press soft key [ETHLOG] and then soft key
[BOARD].
4 To change to storage mode, press soft key [STORAGE].
To change to FTP mode, press soft key [FTP].
To change to buffer mode, press soft key [BUFFER].
5 Press soft key [EXEC].
NOTE
1 Operations in the buffer mode need the optional
buffer mode functions.
2 The Series 21i-A/B cannot use the buffer mode.
