Ethernet/Data Server Board Operators manual Page 157

Operators manual
B-63354EN/04 IV. OPERATION 4.16i/18i DATA SERVER FUNCTIONS
- -143
4.2.7 Deleting a Directory from the Data Server Board Built-in Hard
Disk
Delete a directory (folder) from the data server board built-in hard disk.
Procedure
1 Display the Hard Disk File Dir screen.
2 Press soft key [(OPRT)].
3 Press the continuation menu key at the right end of the soft key
menu.
4 Press soft key [D DEL].
5 Enter the name of a directory (folder) to be deleted from the data
server board built-in hard disk, using the MDI keys.
[Input format]
<Directory number>
or
<Directory name>
6 Press soft key [EXEC].
7 During deletion, "DELETE" blinks in lower-right part of the
screen.
NOTE
1 If a directory (folder) contains files, an attempt to
delete it ends in an error. Before deleting a directory,
delete all files from the directory.
2 A directory to be deleted can be specified using a
directory number only if the directory is displayed on
the Hard Disk File Directory screen.
