B-63354EN/04 IV. OPERATION 4.16i/18i DATA SERVER FUNCTIONS

- -155

4.3.3 Deleting a Host File

Delete files stored on the host computer built-in hard disk.

Procedure

1 Display the Host File Dir screen.

2 Press soft key [(OPRT)].

3 Press soft key [F DEL].

4 Enter the number or name of the file to be deleted using the MDI

keys.

[Input format]

<file-number> or <file-name>

5 Press soft key [EXEC].

6 During deletion, "DELETE" blinks in the lower-right part of the

screen.

NOTE

1 Specifying the file to be deleted with its file number is

valid only for those files displayed on the Host File Dir

screen.

2 Information displayed at the right end of the HOST

FILE DIR (detail) screen is recognized as a file name.

Therefore, when deleting a host file by specifying its

file number from the HOST FILE DIR (detail) screen,

confirm that the file name is displayed at the right end

of the screen, then specify the file number.

3 If a host file name contains kanji, hiragana, or

katakana characters, switch the HOST FILE DIR

(detail) screen to the HOST FILE LIST screen,

specify the file number, then delete the host file.
