B-63354EN/04 V. CONNECTION 2.SETTING

- -295

2.2 Heat Dissipation

The heat dissipation values for the Ethernet board and data server board

are listed in the table below. For the heating values of the system unit

of the CNC or other option units, refer to the connection manual

supplied with the CNC.

Ethernet board

HDD data

server board

ATA data

server board

Board only 6 W 6 W 6 W (Note 1)

Hard disk drive unit - 13 W -

ATA flash card - - 0.3 W (Note 2)

Total 6 W 19 W 6.3 W

NOTE

1 Some data server boards for indicator-separated

control units (Series16i/18i-A) have the RISC option

implemented on a printed circuit board. The

dissipation values shown above do not include that

for the RISC option. For details of the RISC option,

refer to the connection manual supplied with the

CNC.

2 The dissipation value of the ATA flash card may vary,

depending on whether a large-capacity card is used

or whether the card specification has been modified.
