Ethernet/Data Server Board Operators manual Page 153

Operators manual
B-63354EN/04 IV. OPERATION 4.16i/18i DATA SERVER FUNCTIONS
- -139
Deleting two or more files
Procedure
1 Display the Hard Disk File Dir screen.
2 Press soft key [(OPRT)].
3 Press soft key [F DEL].
4 Enter the names of the files (including wild cards) to be deleted
using the MDI keys.
[Input format]
<file-name (including wild cards)>
5 Press soft key [EXEC].
6 When "FILE DELETE" is displayed in the lower-left part of the
screen, press soft key [EXEC]. To cancel the deletion, press soft
key [CAN].
7 During deletion, "DELETE" blinks in lower-right part of the
screen.
8 To stop the deletion, press soft key [STOP].
[Example]
Enter the file name as *.* to delete all the files displayed on the Hard
Disk File Dir screen from the data server board built-in hard disk.
NOTE
When two or more files are being deleted, if soft key
[STOP] is pressed, the files deleted prior to soft key
[STOP] being pressed cannot be restored.
