Ethernet/Data Server Board Operators manual Page 208

Operators manual
4.16i/18i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04
- -194
4.11.1 Checking the Hard Disk
Check whether the hard disk contains a faulty sector.
Procedure
1 Place the CNC in MDI mode.
2 Press function key
SYSTEM
.
3 Press the continuation menu key at the right end of the soft key
menu.
4 When you press soft key [DS-MIN], the Maintenance of Data
Server screen appears.
5 Press soft key [MIN].
6 When you press soft key [CHK DSK], the results are displayed on
the screen.
• Normal : "CHECK DISK:NORMAL"
• Abnormal: "CHECK DISK:ABNORMAL"
CAUTION
If an abnormal condition occurs, check the cause of
the error by referencing the error message displayed
on the Ethernet Error Message screen. Back up the
files on the hard disk as quickly as possible.
Subsequently, format the hard disk.
NOTE
An error is likely to occur if hard disk check is
performed concurrently with other data server
functions.
