Ethernet/Data Server Board Operators manual Page 189

Operators manual
B-63354EN/04 IV. OPERATION 4.16i/18i DATA SERVER FUNCTIONS
- -175
4.8.2 Outputting the Parameter
Output files (NC parameters) from part program storage to the data
server built-in hard disk or host computer built-in hard disk.
For the Parameter screen
Procedure
1 Place the CNC in EDIT mode.
2 Press function key
SYSTEM
.
3 Press the continuation menu key at the right end of the soft key
menu.
4 When you press soft key [PARAM], the Parameter screen is
displayed.
5 Press soft key [(OPRT)].
6 Press the continuation menu key at the right end of the soft key
menu.
7 Press soft key [PUNCH].
8 Press soft key [EXEC].
9 During output, "OUTPUT" blinks in the lower-right part of the
screen.
File name
Fixed to PRAMETER.
File formats and restrictions
Refer to the corresponding CNC operator's manual.
Output destination
In storage mode : Data server board built-in hard disk
In FTP mode : Host computer built-in hard disk
In buffer mode : Data server board built-in hard disk
