Ethernet/Data Server Board Operators manual Page 267

Operators manual
B-63354EN/04 IV. OPERATION 6.15i
i i
i DATA SERVER FUNCTIONS
- -253
[Example]
To input file O0001.DAT from the data server board built-in hard disk
to tape memory, enter O0001.DAT. However, the O number to be input
to tape memory depends on that described in file O0001.DAT.
NOTE
1 An NC program cannot be input concurrently with NC
program input, DNC operation, and DNC operation
by a subprogram call (M198).
2 The O number used for input to tape program
memory depends on the description in the file.
3 In the buffer mode, neither the Hard Disk File
Directory screen nor the Host File Directory screen
can be used for NC program input.
