B-63354EN/04 VI. MAINTENANCE 2.Series 15i

i-A MAINTENANCE INFORMATION

- -361

STATUS LED indications if an error occurs (LED0 through LED 3)

If an error occurs, the LEDs repeatedly flash "LONG" then "SHORT."

(For "LONG," the LED lights for a long time. For "SHORT," the LED

lights for a short time.)

STATUS LED

indication

No.

LONG

3 1

2 0

SHORT

3 1

2 0

Data server board state

n¨

¨¨

¨n

System reset

n¨

¨¨

¨n

¨¨

Machine check

n¨

¨¨

¨n

Failure caused by

this board

DRAM parity alarm

n¨

¨n

¨¨

Failure caused by

another board

NMI of another module

NOTE

If an error, indicated by repeatedly flashing a

LONG and SHORT combination other than the

above, occurs, contact FANUC.

ALARM LED indications if an error occurs

No. LED indication Data server board state

1 PARITY n Parity error occurred in main memory.

LED indication related to communication status

No. LED indication Communication status

1 TPPIL n Lights when the data server board is successfully

connected to the hub.

2COL n Lights if a data collision occurs.

3RX n Lights when data is received.

4TX n Lights when data is sent.

NOTE

TPPIL:

Communication is not performed while this LED is

off. A probable reason for this is that the data

server board is not properly connected to the hub,

or that the hub is off. This LED should be lit at all

times while the Ethernet board is properly

connected to the hub.

COL:

This LED lights frequently if there is excessive

traffic on the communication line or if there is

excessive peripheral electrical noise.
