Ethernet/Data Server Board Operators manual Page 282

Operators manual
6.15i
i i
i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04
- -268
6.8.4 Outputting Tool Offsets
A file (tool offset values) is output from tape memory to the data server
board built-in hard disk or host computer built-in hard disk.
For the Tool Offset screen
Procedure
1 Press function key
OFFSET
SETTING
.
2 Press soft key [CHAPTER].
3 When you press soft key [TOOL OFFSET], the Tool Offset
screen appears.
4 Press the operation menu key at the right end of the soft key
menu.
5 Press soft key [PUNCH].
6 Enter the file name using the MDI keys.
7 Press soft key [TOOL OFFSET].
8 During output, PNCH blinks at the top of the screen.
File formats and restrictions
Refer to . the Series 15i-A Operator's manual (B-63324EN)
Output destination
Storage mode : Data server board built-in hard disk
FTP mode : Host computer built-in hard disk
Buffer mode : Data server board built-in hard disk
