Manual Guide (for Milling) Operators manual Page 100

Operators manual
5. PROGRAM CHECKING OPERATION B-63424EN/03
-88-
5.2 ANIMATED SIMULATION
By pushing [CHECK], the following soft-keys are displayed.
The meaning of each soft-key are as follows.
[PATH]
: Switch to the tool path drawing screen.
[PLAN]
: Display a plan view of a work-piece.
[START]
: Start drawing after drawing a blank and
performing the head search operation.
[ROTATE]
: Rotate a generated drawing.
[CROSS]
: Display a cross-sectional view of a work-piece.
[3-PLAN]
: Display a tri-plane view from a drawn machining
profile.
[PARAM]
: Change the drawing parameters.
5.2.1 Rotation
A drawing can be rotated.
By pushing a [ROTATE], the following soft-keys are displayed.
The meaning of each soft-key are as follows.
[CW ROTATE]
: Rotate a blank in the + direction around the
vertical axis.
[CCW
ROTATE]
: Rotate a blank in the - direction around the
vertical axis.
[END]
: Push when setting is completed.
A rotated blank is drawn when [START] is pressed after [END].
RETURN
PARAM3-PLAN
CROSS
ROTATE
STARTPLANPATH
SET
END
CCW
ROTATE
CW
ROTATE
