Manual Guide (for Milling) Operators manual Page 281

Operators manual
B-63424EN/03
TYPES OF CYCLE MOTIONS
8. MEASURING CYCLES
(OPTIONAL FUNCYION)
-269-
8.11 4- HOLES CENTER MEASUREMENT (G190)
This is a menu for measuring a center position and radius of 4 holes.
By pushing the soft-key [4-HOLE], the following pop-up window is
displayed.
MOVEMENTS
: The movement on the measurement is as follows
HEIGHT
FOR Z AXIS
: Input the height from the measuring start point to
the point which will be measured.
HOLE NOMINAL
DIA.
: Input the nominal diameter of the hole.
1ST HOLE
POINT X / Y
: Input the approximate X and Y coordinate of 1
st
measuring hole center.
2ND HOLE
POINT X / Y
: Input the approximate X and Y coordinate of 2
nd
measuring hole center.
3RD HOLE
POINT X / Y
: Input the approximate X and Y coordinate of 3
rd
measuring hole center.
4TH HOLE
POINT X / Y
: Input the approximate X and Y coordinate of 4
th
measuring hole center.
FEEDRATE
FOR MOV
: Input the feed-rate for movement on measuring.
WORK CO-ORD.
SYST.
: Select the work-piece coordinate system from the
soft-keys.
[G54],[G55],[G56],[G57],[G58],[G59]
If Work-piece Coordinate System 48-pairs is
available, input the number which will be set as
follows.
G54.1P1 ↔ P48 : 1001 ↔ 1048
HEIGHT FOR Z AXIS Z=
HOLE NOMINAL DIA. D=
1ST HOLE POINT X A=
1ST HOLE POINT Y B=
2ND HOLE POINT X C=
2ND HOLE POINT Y E=
3RD HOLE POINT X H=
3RD HOLE POINT Y I=
4 HOLES CENTER 1/2
4TH HOLE POINT X J=
4TH HOLE POINT Y K=
FEEDRATE FOR MOV F=
WORK CO-ORD. SYST. W=
4 HOLES CENTER 2/2
