Manual Guide (for Milling) Operators manual Page 232

Operators manual
5. POCKETING TYPES OF CYCLE MOTIONS B-63424EN/03
-220-
CYCLE
SELECT
: Select the drilling cycle for pre-hole from the
following soft-keys.
[G81 (Normal drilling)], [G83 (Peck drilling)]
( For HOLE only )
PITCH DEPTH
: The depth of cut for each cutting cycle.
It is used for G83 only.
( For HOLE only )
GROOVE
WIDTH
: The width of the groove.
By pushing [DETAIL], the following pop-up window is displayed.
CLEARANCE
: The amount of clearance for cutting feed in the Z
axis at the approach or escape movement. The
default data is 3mm.
CUT
DIRECTION
: Select the cutting direction from the following
soft-keys.
[DOWNCT (down-cut)], [UPCUT (up-cut)]
Down-cut : Rotation of the cutting tool in the
forward direction.
Up-cut : Rotation of the cutting tool in the
reverse direction.
CLEARANCE L= 3.000
CUT DIRECTION U= DOWNCT
CONTOUR GROOVE
(
DETAIL
)
Previous page
Next page
