Manual Guide (for Milling) Operators manual Page 202

Operators manual
4. SIDE CUTTING TYPES OF CYCLE MOTIONS B-63424EN/03
-190-
ESCAPE
RADIUS /
ANGLE
: The radius and angle of tangent circle escape.
ESCAPE DIST.
: The distance of tangent line or vertical line
escape.
After inputting the necessary data, by pushing INSERT, pop-up
window is closed and inputted data are displayed in a program window
as the following ISO code program.
l Definition of arbitrary shape
Arbitrary shape is defined by using [CONTUR] of G code menu.
In detail, refer to “II. OPERATION, 3.2.8 Contour”.
After inputting the necessary data, by pushing INSERT, pop-up
window is closed and inputted data are displayed in a program
window as the following ISO code program.
G224 P L Z S D B J H F C E U •
••
• •
••
• •
••
• •
••
• ;
Radius
An
g
le
Distance
Tangent Line
Vertical Line
Distance
G100 X Y ;
G101 X Y M N L K ;
-
-
G106 X Y P ;
