Manual Guide (for Milling) Operators manual Page 65

Operators manual
B-63424EN/03 OPERATION
3. PROGRAMMING OPERATIONS
-53-
3.4.2 Contour Repetition
In contour program by using [CONTUR] in the Editing menu, a series
of figures can be automatically repeated several times. There are three
repetition types.
This function helps the operator to program even complicated figures
easily.
By pushing [CONTUR], the following soft-keys are displayed.
Push the right-end soft-key [+] and the following second soft-keys is
displayed.
Three repetition types [TRANS], [ROTATE] and [MIRROR] can be
done.
l Translate copy
The linear movement can be repeated a specified number of times,
with the end point of a specified figure used as the start point.
By pushing [TRANS], the following pop-up window is displayed.
NO. OF
REPEAT
: Specify the repetition count.
N
O. OF REPEAT R=
TRANSLATE COPY 1 / 1
RETURN
RECAL.TANGNT
ENDROUND
CHAMF
CW
ARC
CCW
ARC
LINE
START
POINT
RETURN
MIRROR
COPY
ROTATE
COPY
TRANS
COPY
