Manual Guide (for Milling) Operators manual Page 51

Operators manual
B-63424EN/03 OPERATION
3. PROGRAMMING OPERATIONS
-39-
1) START POINT
By pushing [START], the following pop-up window is displayed.
Usually, pushing [CONTOUR] on an Editing menu first causes
the following [START POINT] window to be automatically
displayed.
START
POINT X, Y
: Input the coordinate (X, Y) of the start point in
the contour figure
START POINT
TYPE
: Select the start point type from the following
soft-keys.
[START] : Start point of external figure
[ISLAND] : Start point of island figure
NOTE
The maximum number of island is 6.
[NXT MVE]: Start point of next groove figure
[DIRECT] : Start point of single cut or
positioning
NOTE
In the case of DIRECT, please be sure to select the
soft-key [END] in the END menu.
ISLAND
Z CO-ORD.
: In the case of ISLAND, input the Z coordinate
of the top island.
GROOVE
Z CO-ORD.
: In the case of NXT MVE, input the Z
coordinate of the escape for moving the next
groove.
MOV TYPE
TO ST. PT.
: In the case of DIRECT, select the moving type
from the following soft-keys.
[RAPID] : Rapid traverse to start point
[CUT] : Cutting motion to start point
FEED RATE
TO ST. PT.
: In the case of DIRECT + CUT, input the feed
rate from the present point to the start point.
FEED RATE
FROM ST. PT.
: In the case of DIRECT, input the feed rate from
the start point.
CUTTER
: (in the case of [DIRECT])
START POINT X X=
START POINT Y Y=
START POINT TYPE E= START
START POINT 1 / 1
Previous page
Next page
