4. GUIDANCE CUTTING OPERATIONS

OPERATION B-63424EN/03

-68-

4.1 SELECTING THE GUIDANCE CUTTING

By pushing the soft-key [TEACH] of the following Editing menu, an

operator can select a Guidance Cutting mode.

4.2 INPUTTING COMMON DATA

By selecting Guidance Cutting, the following Common Data items are

displayed in a Pop-up Window.

TOOL NO.

: Number of tool used for guidance cutting

D CODE NO.

: Number of tool used D code for guidance cutting

FEED RATE

: Feedrate at playback machining

SPINDLE

SPEED

: Spindle speed of tool used for guidance cutting

By pushing [INPEND], the common data is defined.

When an operator wants to set or refer to the common data again, he

can do it by pushing the soft-key [COMMON].

GUIDANCE CUTTING

TOOL NO. T=

D CODE NO. D=

FEED RATE F=

SPINDLE SPEED S=

RETURN

TEACHCYCLECONTRPOSTIN

MSF COMPTOOLINIT
