A. PARAMETERS APPENDIX B-63424EN/03

-302-

ATR 1 : The item of ANIMATION T RADIUS (R) is displayed on the

screen of TOOL SET menus.

0 : The item of ANIMATION T RADIUS (R) is not displayed on

the screen of TOOL SET menus.

G41 Specifies which tool path is output during side-facing and pocket

side-facing as follows:

1 : A tool path with cutter compensation used is output.

0 : A tool path with no cutter compensation used is output.

Caution) If G41 = 1, the cutter compensation C optional

function is necessary.

G68 1 : The message of the mode for 3-dimensional coordinate

conversion is displayed on the CNC status area.

0 : The message of the mode for 3-dimensional coordinate conversion

is not displayed on the CNC status area

ISM Specifies how to display input items in the initial setting menu, as

follows:

1 : The "travel distance command," "plane selection," and "unit of

inputs" are displayed in the first section of the window.

0 : The "travel distance command," "plane selection," and "unit of

inputs" are displayed in the detail window.

9106 TOLCHG

TOLCHG Sub program number called tool change sequence instead of M6

Valid data range 0 to 9999

Units 1

FANUC standard settings 0

9107 NCD WDS WGP

FANUC standard settings 00000000

WGP Specifies axis movement on the boring machine as follows:

1 : W-axis movement (parallel to the Z-axis) as well as Z-axis

movement is taken into account for drawing.

0 : W-axis movement (parallel to the Z-axis) is not taken into account

for drawing.

WDS Specifies whether to enable the [FULL ON/OFF] soft key for tool path

and animated simulation drawings, as follows:

1 : The [FULL ON/OFF] soft key is enabled.

0 : The [FULL ON/OFF] soft key is disabled.

NCD Specifies whether to display NC statements if the [FULL ON/OFF] soft

key is enabled (WDS = 1), as follows:

1 : NC statements are displayed on the drawing screen.

0 : NC statements are not displayed on the drawing screen.
