2. PRE-SETTING OF THE OPERATIONS

OPERATION B-63424EN/03

-20-

2.3 SETTING OF DISPLAYING WINDOW

By pushing a [SETTNG], the following pop-up window for displaying

the work figure is displayed on the screen. These data are defining

automatically by setting the INITIAL SET menu. So, in ordinary case,

an operator needs not to set or refer to it. When more detailed control

for display, set to these data if necessary.

The meanings of each parameter are described below.

1) WORK FIGURE

Select whether a work figure is displayed or not.

2) COORDINATE

This parameter specifies a type of drawing screens. ( Only X-Y

plane is available at present. )

3) SCALE MAX. / MIN.

The maximum drawing coordinates (X, Y, Z) / minimum drawing

coordinates (I, J, K) are set. ( Usually these scale factors are

automatically determined so that this parameter need not be set. )

4) COLOR

Seven colors (white, red, green, yellow, blue, purple, and light

blue) are available for selection.

- PATH : Specify the color for drawing the tool path. ( It is

not available at present. )

- WORK : Specify the color for drawing the work figure.

PROGRAMING FIGURE SETTING

WORK FIGURE = ON

COORDINATE = XY

SCALE MAX X AXIS = 0.000

Y AXIS = 0.000

Z AXIS = 0.000

SCALE MIN X AXIS = 0.000

Y AXIS = 0.000

Z AXIS = 0.000

COLOR PATH = WHITE

WORK = WHITE
