Manual Guide (for Milling) Operators manual Page 60

Operators manual

Page of 332

/ 332

3. PROGRAMMING OPERATIONS

OPERATION B-63424EN/03

-48-

An operator can select the point to be defined by inputting the

number.

By pushing INSERT, inputted data are inserted into the selected

block as the following ISO code program.

3.2.7 Cycles

This is the menu which is defined milling cycle machining.

By pushing [CYCLE] soft-key, the following menu soft-keys are

displayed.

The general of each menus are as follows.

• HOLE : Defining the cycle machining of hole

• PATTERN : Defining the hole pattern

• FACE : Defining the cycle machining of facing

• SIDE : Defining the cycle machining of side cutting

• POCKET : Defining the cycle machining of pocketing

For details, refer to “III. TYPES OF CYCLE MOTIONS”.

NOTE

In these cycle motions, please be sure not to use the

cutter compensation function such as G41 or G42.

3.2.8 Teaching

This is the menu which an operator executes the guidance cutting.

For details, refer to “II. OPERATION - 4. GUIDANCE CUTTING

OPERATIONS (OPTION)”.

RETURNPOCKET

FACE

SIDE

PATTERHOLE

(G101,,,,105) X Y •

••

• •

••

• •

••

• •

••

• P ;

Number of a intersect point
