3. PROGRAMMING OPERATIONS

OPERATION B-63424EN/03

-24-

l Search a program

1) Input the program number, which you want to search, to the

key-in buffer

2) By pushing [SEARCH], the program is searched.

3.1.2 Selecting of Soft-key Menus

MANUAL GUIDE classified the complicated ISO codes into several

menus. Therefore, by selecting Icon menu soft-keys, an operator can

create ISO code program easily.

After inputting program number and name, by pushing [EDIT] of the

initial soft-keys, The following soft-keys of Editing menu are

displayed.

In MANUAL GUIDE, this menu is called “ Editing menu ”.

The general of Editing menu are as follows.

• INIT : Definition of work coordinate system, blank form

data

• TOOL : Definition of tool data

• MSF : Instruction of M, S, F code except G code

• COMP : Instruction of cutter or tool length compensation

• POSTIN : Instruction of Line figure

• CONTUR : Instruction of Contour figure ( Line + Circle )

• CYCLE : Definition of canned cycles such as drilling, milling

• TEACH : Guidance cutting operation and teaching

• RETURN : Return to the former soft-keys

NOTE

As to [TEACH] menu, please refer to “4. GUIDANCE

CUTTING OPERATIONS (OPTION)”.

RETURN

TEACHCYCLECONTRPOSTIN

MSF COMPTOOLINIT
