3. FACING TYPES OF CYCLE MOTIONS B-63424EN/03
-166-
3.2 CIRCLE SURFACE (G211)
This is a menu for facing the surface on a circle shape plane.
By pushing [CIRCLE], the following pop-up window is displayed. The
all items are changed according to “MACH. PROCESS”.
MACH.
PROCESS
: Select the machining process from the following
soft-keys.
[ROUGH (cutting)], [FINISH (cutting)]
END POINT Z
: Z coordinate of the final machined surface.
REMOVAL
DEPTH
: The machining allowance in the Z direction of the
cutting surface. ( For ROUGH only )
REMOVAL
PITCH
: The machining allowance of one pass for rough
cutting in the Z direction. Rough cutting is done in
one pass if no input. ( For ROUGH only )
FINISHING
ALW.
: The machining allowance in the Z direction for
finish cutting. This is cut in one pass. Finish
cutting is not done if no input. ( For ROUGH
only )
FEED RATE
: The feed rate of the tool.
CUTTING
WITDH
: The machining allowance of one pass in the XY
direction. It is specified a rate (%) of the tool.
(less than 70%)
CENTER POINT
X / Y
: X and Y coordinate of the center of the circular
surface.
RADIUS
: The radius of the circular surface.
MACH. PROCESS P= ROUGH
END POINT Z Z=
REMOVAL DEPTH B=
REMOVAL PITCH J=
FINISHING ALW. H= 0.000
FEED RATE F=
CUTTING WITDH C= 70.000
CIRCLE FACE 1 / 2
CENTER POINT X X=
CENTER POINT Y Y=
RADIUS R=
CIRCLE FACE 2 / 2
•
••
