Manual Guide (for Milling) Operators manual Page 79

Operators manual

Page of 332

/ 332

B-63424EN/03 OPERATION

4. GUIDANCE CUTTING OPERATIONS

-67-

4 GUIDANCE CUTTING OPERATIONS

(OPTIONAL FUNCTION)

As described in Chapter “I.2 GUIDANCE HANDWHEEL”, an

operator can carry out machining along a tapered or arc figure by using

a guidance handwheel. And also, he can enter the motion block into

program memory, this entering operation is called “Teaching-in”. And

the program is called “Playback Machining Program”. By using this

playback machining program, an operator can carry out same

machining motions repeatedly later on.

NOTE

1) Before selecting the guidance cutting, be sure to set

the work coordinate system of INITIAL SET menu.

Because, the guidance cutting or teaching will be

done on the work coordinate system which is

selected at present.

2) Be sure to set the blank form data of INITIAL SET

menu. Because, the tool path of teaching is drawn on

the scale of the blank form data.
