Manual Guide (for Milling) Operators manual Page 41

Operators manual
B-63424EN/03 OPERATION
3. PROGRAMMING OPERATIONS
-29-
By pushing [DETAIL], the following pop-up window is
displayed.
ABS / INC
: Select the command travels from the following
soft-keys.
[ABS: G90], [INC: G91], [NO OUT: no
instruction]
PLANE
SELECTION
: Select the used plane from the following soft-
keys.
[XY-PLANE: G17], [ZX-PLANE: G18],
[YZ-PLANE: G19], [NO OUT: no instruction]
ORIGIN POINT
: Select the blank origin point from the following
soft-keys.
[CENTER], [DOWN-LEFT]
INPUT UNIT
: (if the inch/metric conversion option is
enabled)
Select the input unit (inch: G20, millimeter:
G21, or no output).
After inputting the necessary data, by pushing INSERT, a pop-up
windows is closed and inputted data are displayed in a program
window as the following ISO code program.
•
••
• In the case of [WINDOW] OFF
In case that a pop-up window is closed, G code or the addresses is
display in a key-in buffer field automatically as the above ISO
code program is created. When the data is not necessary, by
pushing INPUT key, the data becomes invalid and the next
addresses is displayed. After repeating this operations, by pushing
INSERT key, and inputted data are decided. ( “;” is inserted.)
ABS / INC A= NO OUT
PLANE SELECTION S= NO OUT
ORIGIN POINT B= CENTER
INITIAL SET
(
DETAIL
)
G300 W P X Y Z I J K (A S B M ) ;
←
←←
← Setting of Initial Data
Previous page
Next page
