5. PROGRAM CHECKING OPERATION B-63424EN/03

-94-

5.4 BACKGROUND DRAWING (OPTION FUNCTION)

This function is a function by which, while machining is in progress,

tool path drawing and animated simulation can be executed

concurrently using another program.

NOTE

This function requires the option function for NC

background drawing.

The operating instructions are the same as those of the conventional

tool path drawing and animated simulation functions, except the

following:

1. Selection of the program with which drawing is to be executed

2. Display and cancellation of alarms that may be generated during

the execution of drawing

3. Screen switching using a function key

4. Display of the operation status on the drawing screen

5.4.1 Selection of the Program with Which Drawing Is to Be Executed

To select a program, first push the soft-key [DIR] and then select the

desired one from the program directory window.

Pushing the soft-key [DIR] causes the following soft-keys to be

displayed. Position the cursor on the desired program No. and push the

soft-key [CHECK], and the program No. is selected and the system

switches to the drawing screen.

If the soft-key [CHECK] is pushed in a window other than the program

directory window, which is displayed by pushing the soft-key [DIR],

the program No. currently selected in the foreground is assumed the

desired program No. and the system switches to the drawing screen. If

the function key GRAPH is pushed, no new program No. is selected,

but the program No. currently selected in the background is assumed

and the system switches to the drawing screen.

RETURN

O-

CNY NC

COPY

DELETECHECK

EDIT
