Manual Guide (for Milling) Operators manual Page 295

Operators manual
B-63424EN/03 SAMPLE OF PROGRAMMING
1. EXAMPLE OF INPUTTING PROGRAM
-283-
8. Instruction of M / S code ( Spindle Stop )
Input the necessary data by MDI key. ( Omission of the detail )
9. Tool Setting ( Tool = Drill for Hole Machining )
Input the necessary data by MDI key. ( Omission of the detail )
10. Instruction of M / S code ( Spindle speed )
Input the necessary data by MDI key. ( Omission of the detail )
11. Instruction of Hole Machining
INSERT
M5 ;
INSERT
G301 T2 D2 H2 R4. ;
INSERT
M3 S5000 ;
RETURN
TAP RGTAP
BOREDRILL
MACHINE PATTERN G= S-PECK
Z POINT DISTANCE Z= -20.000
R POINT DISTANCE R= 2.000
PITCH DEPTH Q= 5.000
FEED RATE F= 50.000
DRILLING CYCLE 1 / 1
RETURN
POCKET
FACE
SIDE
PATTERHOLE
INSERT
G73 Z-20. R2. Q5. F50. K0 ;
RETURN
TEACH
CYCLE
CONTRPOSTIN
MSF COMPTOOLINIT
RETURN
TEACH
CYCLE
CONTRPOSTIN
MSF COMPTOOLINIT
RETURN
TEACH
CYCLE
CONTRPOSTIN
MSF COMPTOOLINIT
