FAPT Macro Compiler (for PC) Programming manual Page 106

Programming manual
Macro library for user module 2
Add these lines to the link file to display the
series and edition of user module 2.
Specify a size of 256K bytes.
Common part shared by user programs
1 and 2
F. CREATING PROGRAMS BY USING
SUPER CAP II M/SUPER CAP II T
WITH Series 16i/18i
B–66102E/10
APPENDIX
96
D Link file for user module 2 (F16MCP2.LNK)
/*
/* Conversation MACRO Sample program LINK control file.
/* ––––––––––––––––––––––––––––––––––––––––––––––––––––––
/*
/* executer file ’FS16MI for VGA’
/*
CNC =F16IMP2.MEX
SERN =USR2
VERN =0001
SYSTEM=MPATH1
/*
/* compile parameter P9000 – P9009 and P9010 – P9059
/*
P9000=10000100
P9001=00000001
P9002=11000000
P9003=10000000
P9007=10000000
P9009=00000010
P9033=12
/*
/* Link file’s
/*
FILE=AUX_PRG
After creating two files as described above, execute MLINK/MMCARD
to create MEM files. The following MEM files are created:
D F16IMP1.MEM: 1.375M bytes
D F16IMP2.MEM: 256K bytes
