FAPT Macro Compiler (for PC) Programming manual Page 180

Programming manual
J. P-CODE LOADER FUNCTION
(FOR Series 20)
B–66102E/10
APPENDIX
170
Address
0103 Baud rate (For I/O CHANNEL=0)
Data type : Byte
Set a baud rate of I/O device for I/O CHANNEL=0 according to Table 2.
Table 2
Set
Baud rate Set Baud rate Set Baud rate
1 50 5 20 9 2400
2 100 6 300 10 4800
3 110 7 600 11 9600
4 150 8 1200 12 19200
Set the same baud rate as the personal computer for P–CODE LOADER.
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
0111 ASI SB2
Data type : Bit
These parameters are those for I/O CHANNEL=1. Meaning of each bit
is the same as parameter no. 101.
Address
0112 Specification number of I/O device (for I/O CHANNEL=1)
Data type : Byte
Set specification number of I/O device when I/O CHANNEL=1
according to Table 1.
Address
0113 Baud rate (I/O CHANNEL=1 )
Data type : Byte
Baud rate of I/O device when I/O CHANNEL=1 according to Table 2.
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
0121 ASI SB2
Data type : Bit
These parameters are those for I/O CHANNEL=2. The meaning of each
bit is the same as parameter no. 101.
Address
0122 Specification number of I/O device (I/O CHANNEL=2)
Data type : Byte
Set the specification number of I/O device for I/O CHANNEL=2
according to Table 1.
Address
0123 Baud rate (I/O CHANNEL=2 )
Data type : Byte
Set baud rate of I/O device for I/O CHANNEL=2 according to Table 2.
