This screen indicates whether the data transfer to flash ROM terminated
normally.
(Normal termination)
MACRO COMPILER/EXECUTER P-CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
ADRxxxxxxH:xx
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 0
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
BAUDRATE =11 ∗∗∗∗∗
STOP BIT = 1
INPUT CODE = 1
LOADING TO FLASH ROM : COMPLETE
PUSH 1 KEY : CNC START WITH EXECUTER
Press the 1 key to terminate P-CODE processing and start the CNC.
If a Series with two–path control is being used, the following message is
displayed.
MACRO COMPILER/EXECUTER P-CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
ADRxxxxxxH:xx
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 0 ∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
BAUDRATE =11 ∗∗∗∗∗
STOP BIT = 1
INPUT CODE = 1
LOADING TO FLASH ROM : COMPLETE
PUSH 1 KEY : RETURN TO HEAD SELECTION
Press the 1 key to return to the path selection screen.
If an attempt to load data into flash ROM fails, the following error
message is displayed.
To start re-loading into flash ROM, press the 1 key.
Press the CAN key and then 1 key on the MDI keyboard to terminate the
P-CODE loader processing and start the CNC. The P-CODE previously
loaded into DRAM is effective.
If a Series with two-path control is being used, the tool post selection
screen is displayed again.
I.2.7
Flash ROM Transfer
End Screen (Except
Series 21)
Previous page
Next page
