G. BOOT SYSTEM (FOR Series 16–B/C,
18–B/C, 20, 21–B, 0i–A)
APPENDIX
109
(4) When saving terminates normally, the system displays the following
message. Press the [SELECT] key. The name of the file written to
the memory card is displayed. Check the file name.
∗∗∗
MESSAGE ∗∗∗
FILE SAVE COMPLETE. HIT SELECT KEY.
SAVE FILE NAME : PMC RB.000
(1) Difference between a system file and user file for SYSTEM DATA
SAVE
SYSTEM DATA SAVE protects system files so that they cannot be
copied easily. User files are not protected.
(2) Names of saved files
The names of the files written from flash memory to the memory card
are as follows:
D Series 16/18
Flash memory Memory card
NC BASIC ! NC_BASIC.XXX
DG SERVO ! DG_SERVO.XXX
NC1 OPTN ! NC1_OPTN.XXX
PMC-RB ! PMC–RB.XXX
PCD 0.5M ! PCD_0.5M.XXX
PCD 1.0M ! PCM_1.0M.XXX
PCD 1.5M ! PCD_1.5M.XXX
D Series 20
Flash memory Memory card
NC BASIC ! NC_BASIC.XXX
DG SERVO ! DG_SERVO.XXX
OPT LANG ! OPT_LANG.XXX
PMC-RA ! PMC–RA.XXX
PCD 0.5M ! PCD_0.5M.XXX
PCD 1.0M ! PCM_1.0M.XXX
PCD 1.5M ! PCD_1.5M.XXX
D Series 21
Flash memory Memory card
NC BASIC ! NC_BASIC.XXX
DG SERVO ! DG_SERVO.XXX
NC1 OPTN ! NC1_OPTN.XXX
PMC-RA ! PMC–RA.XXX
PCD 128k ! PCD_128k.XXX
PCD 256k ! PCD_256k.XXX
PCD 0.5M ! PCD_0.5M.XXX
PCD 1.0M ! PCM_1.0M.XXX
XXX is equivalent to the extension assigned to MS-DOS file names.
One of 32 numbers from 000 to 031 is assigned as XXX. For
example, if a PMC-RB file in flash memory is saved to a memory card
containing no PMC_RB.* files, the saved file is named
PMC_RB.000. If that same file is saved to a memory card that
already contains a PMC_RB.000 file, however, it is named
PMC_RB.001. In this way, the extension is incremented by one, up
to PMC_RB.031. If there are any free extension numbers in the
sequence of the extension numbers, they are used in ascending order.
If two or more files having identical names but different extension
numbers are saved to a single memory card, check the file names
displayed after saving. In the case of Serics 20, to write a P-CODE
macro file, with a password assigned by MLINK, from flash memory
to a memory card, the password must be entered. The macro
password is explained in Sec.G.4.
