I. P–CODE LOADER FUNCTION
(FOR Series 16–B/C, 18–B/C,
21–TA, Series 16i/18i/21i–A/B)
B–66102E/10
APPENDIX
146
When a Series with two-path control is being used, the path selection
screen is displayed subsequent to the title screen, as shown below.
By pressing the M or S address key, select path 1 or 2.
If the 0 key is pressed, P-CODE loader processing is terminated and the
Series 16/18–B/C system is activated.
MACRO COMPILER/EXECUTER P-CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 0
BAUDRATE =11
STOP BIT = 1
INPUT CODE = 1
LOADING PATH 1 : YES (PUSH M KEY)
LOADING PATH 2 : YES (PUSH S KEY)
LOADING END : YES (PUSH 0 KEY)
Series with two-path control is being used
When a system other than Series with two-path control is used, the
following screen is displayed. The macro executor RAM is initialized.
If a Series with two-path control is used, the following screen is displayed
after either path is selected. Then, the macro executor RAM is initialized.
MACRO COMPILER/EXECUTER P-CODE LOADER
PATH 1/PATH 2
(I/O PARAMETERS) (DATA TRANSFER)
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 0
BAUDRATE =11
STOP BIT = 1
INPUT CODE = 1
OMM D-RAM INITIALIZE
z This line is displayed only for two–
path control. The same applies to
the subsequent screens.
I.2.2
RAM Initialization
Screen
