FAPT Macro Compiler (for PC) Programming manual Page 233

Programming manual
Revision Record
FAPT MACRO COMPILER(For Personal Computer) PROGRAMMING MANUAL (B–66102E)
05 Jul., 1995
• Addition of Series 21–MB.
• Addition of APPENDIX 11 BOOT SYSTEM (For Series
15–B).
• Correction of errors.
10 Jul., 2001 Addition of Series 16i/18i/21i/160i/180i/210i–MODEL B
04 Jan., 1995
• Addition of Series 21–TB
• Addition of APPENDIX 10 DATA INPUT/OUTPUT WITH
MEMORY CARDS (SYSTEM MONITOR FUNCTION only
for Series 21–TB).
09 Jul., 2000 Addition of Series 0i–MODEL A
03 Mar., 1994 Addition of Series 16–B. 08 Sep., 1999 Addition of Series 15i–MODEL A
02 Mar., 1993
Addition of Series 18.
Addition of Series 20.
07 Jul., 1997 Addition of Series 16i/18i/21i/160i/180i/210i–MODEL A
01
Jul., 1991
06
Jan., 1997 Addition of Series 16/18/160/180–MODEL C.
Edition Date Contents Edition Date Contents
Previous page
Next page

Contents Summary of FAPT Macro Compiler (for PC) Programming manual

  • Page 1GE Fanuc Automation Europe CNC Controls FAPT MACRO COMPILER For PersonalComputer Operator's Manual B-66102EN/10 TECHNOLOGY AND MORE
  • Page 2Ȧ No part of this manual may be reproduced in any form. Ȧ All specifications and designs are subject to change without notice. The export of this product is subject to the authorization of the government of the country from where the product is exported. In this manual we have tried as much as possi
  • Page 3B–66102E/07 DEFINITION OF WARNING, CAUTION, AND NOTE DEFINITION OF WARNING, CAUTION, AND NOTE This manual includes safety precautions for protecting the user and preventing damage to the machine. Precautions are classified into Warning and Caution according to their bearing on safety. Also, suppleme
  • Page 4
  • Page 5B–66102E/10 PREFACE PREFACE The models covered by this manual, and their abbreviations are : Product Name Abbreviations FANUC Series 0–MODEL A, B, C 0–A/B/C Series 0–A/B/C Series 0 FANUC Series 0i–MODEL A 0i–A Series 0i–A FANUC Series 15–MODEL A 15–A Series 15–A FANUC Series 150–MODEL A 150–A FANUC
  • Page 6PREFACE B–66102E/10 Product Name Abbreviations FANUC Series 21–TA 21–TA Series 21–A FANUC Series 21–TB 21–TB *1 FANUC Series 210–TB 210–TB Series 21–B FANUC Series 21–MB 21–MB FANUC Series 210–MB 210–MB Series 21 FANUC Series 21i–A 21i–A Series 21i–A FANUC Series 210i–A 210i–A FANUC Series 21i–B 21i
  • Page 7B–66102E/10 Table of Contents DEFINITION OF WARNING, CAUTION, AND NOTE . . . . . . . . . . . . . . . . . . . . . . . . . . s–1 PREFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p–1 1. GENERAL . . . . . . . . . . .
  • Page 8Table of Contents B–66102E/10 APPENDIX A. SYSTEM COMMON SYMBOL DEFINITION (\MCOMP\TOOL\SYSTEM.DEF) . 39 B. COMPILE ERROR CODE TABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 C. ROM WRITE/VERIFICATION PARAMETER TABLE . . . . . . . . . . . . . . . . . . . . . .
  • Page 9B–66102E/10 Table of Contents G.2.3 System Data Delete Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106 G.2.4 System Data Save Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
  • Page 10Table of Contents B–66102E/10 J.2.4 Loading End Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164 J.2.5 Menu for Transferring Data into FLASH ROM Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
  • Page 11B–66102E/10 1. GENERAL 1 GENERAL The MACRO Compiler/Executor function stores programs created using custom macros (macro programs) in ROM so that machine tool builders can implement their own conversational screens. The FAPT MACRO Compiler is a macro compiler utility to implement the MACRO Compiler/
  • Page 121. GENERAL B–66102E/10 1.1 FEATURES (1) Macro programs can be edited using a commercially available screen editor that operates under the MS-DOS environment. (2) The symbolic macro compiler function allows macro programs to be coded in symbolic format, and also allows comments to be coded. (3) A pro
  • Page 13B–66102E/10 1. GENERAL 1.2 OVERVIEW The FAPT MACRO Compiler/Executor function enables the FANUC CNC users to develop their own macro programs in a macro language, store the macro programs in ROM as a macro ROM by using the macro compiler, and execute the macro programs with the macro executor functi
  • Page 141. GENERAL B–66102E/10 * Create a macro program using an editor. (An editor is MS-DOS not supplied.) Editor * The macro program (source file) must be in standard Macro Program MS-DOS text format. (Source file) MCOMP0 MCOMP15 MCOMP15I * The macro compiler generates an object file. It also MACRO creat
  • Page 15B–66102E/10 2. EQUIPMENT CONFIGURATION 2 EQUIPMENT CONFIGURATION (1) Personal computer: (Fujitsu : FMR Series) (NEC : PC98 Series) (IBM : PC-AT Series) Main memory 640K bytes or more OS (FMR/PC98) MS-DOS Version 3.1 and later (PC-AT) PC-DOS Version 3.3 and later Hard disk About 1M bytes is required
  • Page 163. SYSTEM INSTALLATION (SETUP) B–66102E/10 3 SYSTEM INSTALLATION (SETUP) The FAPT MACRO Compiler software is distributed with two 5-inch (2HD) floppy disks or 3.5-inch (2HD) floppy disk for series 15i/16i/18i/21i. To use the software, load the software to the hard disk from the system floppy disks.
  • Page 17B–66102E/10 3. SYSTEM INSTALLATION (SETUP) 3.1 This operation installs the FAPT MACRO Compiler system software on the hard disk. First set the FAPT MACRO Compiler system floppy disk INSTALLING THE in the floppy disk drive, then activate MSETUP.BAT on the floppy disk. SYSTEM FROM THE > ?: \ > MSETUP
  • Page 183. SYSTEM INSTALLATION (SETUP) B–66102E/10 d) \MCOMP\USR\SAMPL Under this directory, the files including such a link control file, compiler/link result files, and program files as described in Appendix D are stored. Use these files as reference information for development. 8
  • Page 19B–66102E/10 3. SYSTEM INSTALLATION (SETUP) 3.2 This operation loads the executor file under the library directory of the FAPT MACRO Compiler system installed by the operation of Section INSTALLING THE 3.1. EXECUTOR FILE As with the FAPT MACRO Compiler system floppy disk, set the FAPT FROM THE FAPT M
  • Page 203. SYSTEM INSTALLATION (SETUP) B–66102E/10 3.3 All system software is contained under the \MCOMP\TOOL directory. So specify this directory by path setting with AUTOEXEC.BAT. PATH SETTING 10
  • Page 21B–66102E/10 3. SYSTEM INSTALLATION (SETUP) 3.4 To match the CNC series, there are three types of the FAPT MACRO Compiler system: COMPILER SERIES a) For Series 0/Series 16/Series 18/Series 20/Series 21 b) For Series 15–A/15–B c) For Series 15i–A These Compiler systems are for the respective series on
  • Page 223. SYSTEM INSTALLATION (SETUP) B–66102E/10 3.5 SPECIFYING ENVIRONMENT VARIABLES 3.5.1 A macro program or a ROM-format file is transferred via the Selecting a RS-232-C/GPIB interface. The interface control systems vary between personal computer manufacturers. Control software including MPOUT, RS–232–
  • Page 23B–66102E/10 4. FUNCTIONS 4 FUNCTIONS 13
  • Page 244. FUNCTIONS B–66102E/10 4.1 MACRO COMPILER (1) Operation (MCOMP0/MCOMP15/ The macro compiler can compile macro programs created in the MS-DOS text file format. The macro compiler outputs an object file MCOMP15i) for the macro linker, reference list file, and compile list file. *1 *2 A:\> MCOMP0 fil
  • Page 25B–66102E/10 4. FUNCTIONS *2 [parameters] This specifies compile conditions. –NR : Outputs no object file. If this parameter is omitted, an object file with the extension .REL is output. –L1 : Outputs no compile list file. If this parameter is omitted, a compile list file with the extension .LST is o
  • Page 264. FUNCTIONS B–66102E/10 (5) Compile list file A compile list file is output as a result of macro program compilation after symbolic macro program analysis. A source program, errors, error codes, variable cross reference information, object file size information, and so forth are listed. The name of
  • Page 27B–66102E/10 4. FUNCTIONS 4.2 MACRO LINKER (1) Operation (MLINK) According to the specification in a link control file created beforehand, the macro linker creates a link list file and ROM-format file for creating a desired macro cassette. *1 *2 A:\> MLINK file-spec [parameters] ==> (For Series 0/16/
  • Page 284. FUNCTIONS B–66102E/10 (2) Link control file The link control file specifies a library file name, compile parameters, and object file names subject to linkage. As with a source file, a link control file must be created in MS-DOS text file format. At this time, be sure to assign the file name exten
  • Page 29B–66102E/10 4. FUNCTIONS (3) Link list file The link list file is output by the linker, and a library name, compile parameters, compile program list and size information, erroneous program numbers, error codes, ROM-format file size information and so forth are listed. The name of a link list file is
  • Page 304. FUNCTIONS B–66102E/10 NOTE 1 For the 21-TB (Controller A), always specify 128 KB. 2 For the Series 16, a 128-KB ROM-format file cannot be specified. 3 For the 21-MB or 21-TB (Controller B), no more than 1.0 MB can be specified. 4 For the 0i–A, no more than 512 KB can be specified. D Series 15i–A
  • Page 31B–66102E/10 4. FUNCTIONS 4.3 A linked ROM-format file can be transferred to CNC memory via a RS-232-C line, and whether the created ROM-format file operates ROM–FORMAT FILE correctly can be checked using the macro executor RAM operation TRANSMITTER (CNC) function of the CNC system. (FOR Series NOTE
  • Page 324. FUNCTIONS B–66102E/10 a) Activate the P-code loader function in the initialization loader function mode specified for the CNC (bit 1 of parameter No. 8701 = 0) to transfer all files from the personal computer. MTRNSC SAMPL.ROM 32 00800000 b) Debug the macro program. c) If an error is found, corre
  • Page 33B–66102E/10 4. FUNCTIONS 4.4 ROM–FORMAT FILE (1) Operation TRANSMITTER A linked ROM-format file is transferred to the FANUC PMC Writer or FANUC FA Writer via a RS-232-C line, and is written to (FANUC PMC a macro ROM and verified. WRITER/FANUC FA A:\> MROMWT file-spec parameters Write or write/verifi
  • Page 344. FUNCTIONS B–66102E/10 4.5 SERIAL INTERFACE UTILITY 4.5.1 Macro Program Input (1) Operation A macro program is read from the CNC/SYSTEM P via a RS-232-C line, then is stored in an MS-DOS text file for the macro compiler. A macro program is transferred from the CNC/SYSTEM P after the command below
  • Page 35B–66102E/10 4. FUNCTIONS 4.6 ROM–FORMAT FILE (1) Operation TRANSMITTER A linked ROM-format file is transferred to the FANUC FA Writer via a GP-IB interface, and is written to a macro cassette and verified. (FANUC FA WRITER, Since a linked ROM-format file is transferred to the FANUC FA GP–IB INTERFAC
  • Page 364. FUNCTIONS B–66102E/10 4.7 CONVERSION TO A (1) Operation Convert a ROM-format file created by the macro linker (MLINK) to MEMORY CARD the memory-card format file which can be loaded from the memory FORMAT (MMCARD) card using the boot function of the Series 15-B/16-B/20. (THIS FUNCTION IS A:\> MMCA
  • Page 37B–66102E/10 5. SYMBOLIC MACRO PROGRAM 5 SYMBOLIC MACRO PROGRAM A macro program is to be created according the rule described below. (1) A macro program must start with address O. Address % must be specified at the end of the file. Multiple programs can be coded in a single file. At this time, the st
  • Page 385. SYMBOLIC MACRO PROGRAM B–66102E/10 Symbolic name definition @xxxx yyyyyy xxxx: Symbolic name (String of alphanumeric characters beginning with an alphabetic character) Version 1.4 or pre- Version 2.1 or subse- Version of the compiler vious versions quent versions Maximum number of 8 32 characters
  • Page 39B–66102E/10 5. SYMBOLIC MACRO PROGRAM Example) @COUNT1 #100 >JUMP1 100 >SKIP 200 /: O0002 ; ==> O0002 ; GOTO JUMP1 ; GOTO 100 ; IF[COUNT1 LE 0]GOTO SKIP ; IF[#100 LE 0]GOTO 200 ; SKIP ; N200 ; JUMP1 M99 ; N100 M99 ; (6) Automatic conversion of hiragana and kanji codes Hiragana and kanji, when coded
  • Page 405. SYMBOLIC MACRO PROGRAM B–66102E/10 (8) Array variable coding Variables can be used as a one-dimensional array by using a simple coding method. Coding method #999 999: Number of first variable in array By this coding method, variables can be referenced or written to as array data with
  • Page 41B–66102E/10 5. SYMBOLIC MACRO PROGRAM IF[&&&&&& ] THEN; –OK IF[|||||| ]GOTO xxx; –OK IF[&&||] GOTO xxx ; –NG Example) IF[#100 EQ 1 && #101 GT 0] GOTO 100 ; IF[#100 E
  • Page 425. SYMBOLIC MACRO PROGRAM B–66102E/10 IF[#100 EQ 0] THEN #101 = 1; ELSE ; #101 = 2 ; GOO X#103 ; ENDIF ; Up to three levels of nesting of the IF statement are allowed. IF [...] THEN ; IF [...] THEN ; Statement ;   ELSE ; IF [...] THEN ; Statement ; ENDIF ; ENDIF ; Statement ;   ELSE ; Statement
  • Page 43B–66102E/10 6. RS-232-C INTERFACE SETTING 6 RS-232-C INTERFACE SETTING To transfer a ROM-format file to the CNC system or FANUC PMC-Writer/FA-Writer for writing to ROM/verification or transfer a macro program, the RS-232-C interface is controlled using the DOS function call (21H) auxiliary I/O devic
  • Page 447. GP-IB INTERFACE SETTING (FOR Series 0, 15–A, 16–A, 18–A) B–66102E/10 GP-IB INTERFACE SETTING 7 (FOR Series 0, 15-A, 16-A, 18-A) The GP-IB interface performs interface processing by using a GP-IB BIOS driver provided by each personal computer supplier. The user is to prepare a GP-IB interface boar
  • Page 45B–66102E/10 8. SYSTEM COMMON SYMBOL DEFINITION FILE 8 SYSTEM COMMON SYMBOL DEFINITION FILE When the system is installed, a system common symbol definition file is stored under the directory \MCOMP\TOOL. For macro program creation, the user should make full use of the symbolic names defined in the fi
  • Page 469. HOW TO VIEW REFERENCE LIST/COMPILE LIST B–66102E/10 9 HOW TO VIEW REFERENCE LIST/COMPILE LIST A source program coded using symbolic macro programs is converted by the macro compiler to a program in custom macro format for compile processing. The macro compiler outputs two types of list files: one
