J. P-CODE LOADER FUNCTION
(FOR Series 20)
APPENDIX
163
Upon completion of RAM area initialization, the loading start menu is
displayed.
MACRO COMPILER/EXECUTER P-CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 1 ––––––––––––––––
BAUDRATE =11 ––––––––––––––––
STOP BIT = 1 ––––––––––––––––
INPUT CODE = 1 ––––––––––––––––
LOADING READY ? : YES/NO
[ ][ ][ YES ][ NO ][ ]
[ YES ] : Starts loading data into DRAM.
[ NO ] : Cancels loading data (IPL menu reappears).
Once preparations for data transfer have been completed on the personal
computer, press the [YES] soft key. The CNC enters the data reception
wait state. To start data transfer, execute the data transfer command (see
Section 4.3) from the personal computer.
When the CNC receives data, the data reception state is indicated, as
shown below.
Under the DATA TRANSFER field, the data being transferred together
with its address, are displayed.
An asterisk
∗ corresponds to about 8k bytes.
MACRO COMPILER/EXECUTER P-CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
ADR xxxxxxH:xx
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 1 ∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
BAUDRATE =11 ∗∗∗∗∗–––––––––––
STOP BIT = 1 ––––––––––––––––
INPUT CODE = 1 ––––––––––––––––
––––––––––––––––
OMM RAM MODULE INITIALIZE
[][][][][]
J.2.2
Loading Start Menu
J.2.3
Loading Menu
Previous page
Next page
