FAPT Macro Compiler (for PC) Programming manual Page 216

Programming manual
M. PARAMETERS
B–66102E/10
APPENDIX
206
DAUXR : The conversational macro screen is displayed when
power is turned on while the system is in the emergency
stop state or external reset state.
(Parameter DAUX (No. 9002, #5) must also be set to 1.)
CNCHG : Execution of the conversational macro is continued when
the CUSTM key is pressed while the conversational
macro screen is displayed.
US19W : The screen for the 9” CRT type is displayed on the 14”
CRT type. (USER-1 screen)
NNUM = 0: When data input control is valid for the CUSTOM screen,
the NUM prompt is displayed.
= 1: When data input control is valid for the CUSTOM screen,
the NUM prompt is not displayed.
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
9007 US19WK TIVR2 TIVR1 TIDSP
TIDSP : The common conversational macro screen for the 2–path
control is specified.
NOTE
This setting is validated only for the PATH-2 cassette.
Both TTDSP and CNCHG (No. 9006, #4) cannot be set to
1 at the same time.)
TIVR1 : Common conversational macro variables (#10000 to
#19999) are specified.
(1: For variables #10000 to #19999, areas #10000 to
#19999 of the other path are used.)
TIVR2 : Common conversational macro variables (#20000 to
#29999) are specified.
(1: For variables #20000 to #29999, areas #20000 to
#29999 of the other path are used.)
US19WK= 0 : When display with 12 soft keys is selected, the position
of the key–in line is not changed on a window having
seven soft keys.
= 1 : When display with 12 soft keys is selected, the position
of the key–in line is changed on a window having seven
soft keys.
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
9008 HRGCC HCAR MDLP AX8CL AX7CL AX6CL AX5CL
AX5CL = 0 : Macro program call by the 5th axis address is made
invalid.
= 1 : Macro program call by the 5th axis address is made valid.
AX6CL = 0 : Macro program call by the 6th axis address is made invalid.
= 1 : Macro program call by the 6th axis address is made valid.
AX7CL = 0 : Macro program call by the 7th axis address is made invalid.
= 1 : Macro program call by the 7th axis address is made valid.
AX8CL = 0 : Macro program call by the 8th axis address is made invalid.
= 1 : Macro program call by the 8th axis address is made valid.
