J. P-CODE LOADER FUNCTION
(FOR Series 20)
B–66102E/10
APPENDIX
164
When loading ends, either of the following screens appears to indicate
whether loading terminated normally. (For normal termination)
MACRO COMPILER/EXECUTER P-CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
ADR xxxxxxH:xx
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 1 ∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
BAUDRATE =11 ∗∗∗∗∗–––––––––––
STOP BIT = 1 ––––––––––––––––
INPUT CODE = 1 ––––––––––––––––
––––––––––––––––
LOADING END : TOTAL xxxxxxxx BYTES
LOADING TO FLASH ROM ? : YES/NO
[ ][ ][ YES ][ NO ][ ]
[ YES ] : Starts writing data into flash ROM memory.
[ NO ] : Cancels writing data into flash ROM memory (IPL menu
reappears).
Specify whether writing data into flash ROM memory is started by
selecting the [YES] or [NO] soft key.
(For abnormal termination)
MACRO COMPILER/EXECUTER P-CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
ADR xxxxxxH:xx
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 1 ∗∗∗∗∗∗∗∗––––––––
BAUDRATE =11 ––––––––––––––––
STOP BIT = 1 ––––––––––––––––
INPUT CODE = 1 ––––––––––––––––
––––––––––––––––
(ERROR OCCURED)
ILLEGAL CHARACTER
LOADING RESTART ? : YES/NO
[ ][ ][ YES ][ NO ][ ]
[ YES ] : Starts reloading data into DRAM.
NOTE
Reloading data is started after DRAM is initialized.
[ NO ] : Terminates loading (IPL menu reappears).
J.2.4
Loading End Menu
Previous page
Next page
