FAPT Macro Compiler (for PC) Programming manual Page 93

Programming manual
B–66102E/10
E. MACRO CONVERTER (MCONV) OPERATION
GUIDE FOR THE FANUC Series 16/18
Super CAP M/Super CAP II M
APPENDIX
83
The table data file output by the macro converter can be converted
together with the object file output by the macro compiler to ROM-format
files with the macro linker.
The following shows an example of specifying a table data file. In the
example, the table data file consists of MENU.TBL for menu definition,
DATA.TBL for conversational data, and KOMK.TBL for data item
display.
/: MACRO COMPILER UTILITY LINK FILE
/
: SYSTEM FILE
CNC=A:\BJ64.PG1
CNC2=A:\BJ64.PG2
CNC3=A:\BJ64.PG3
/
: LINK PARAMETER
P9000=11000000
P9001=00000001
P9002=11000000
P9003=10000000
P9007=10000000
P9033=12
P9037=5
9038=8000
/
: MACRO PROGRAM
FILE=ABC,DEF
/
: TABLE DATA
TBL=MENU,DATA,KOMK
/
:
The link list file to be output by the linker contains a table data file name,
program numbers, and program size as well as macro program functions.
The file name is the same as that of the link control file but the extension
is replaced with MAP.
E.3
CONVERSION OF
TABLE DATA WITH
THE MACRO LINKER
(MLINK)
E.3.1
Outline
E.3.2
Link Control File
E.3.3
Link List File
