FAPT Macro Compiler (for PC) Programming manual Page 195

Programming manual
B–66102E/10
K. BOOT SYSTEM (FOR Series 15-B/15i-A)
APPENDIX
185
(3) Turn on the power of the CNC unit while holding down the cursor (←
and →) keys, and the boot system is activated. Refer to ”K.3
STARTING THE BOOT SYSTEM”.
(4) Check the contents of F-ROM. If a P-CODE file is already registered,
delete it. For the deletion procedure, see 2 Procedure for registering
a P-CODE file in a memory card to F-ROM, steps (3) to (7) in
Sec.K.4.
(5) Select ”SYSTEM DATA LOADING” using the cursor keys, then
press the input key. The following contents of the ROM cassette are
read and displayed on the screen:
SYSTEM DATA LOADING (CASSETTE)
P-CODE 256K (WITHOUT SUB-CPU)
∗∗∗ MESSAGE ∗∗∗
SELECT FILE AND HIT INPUT KEY
Title
ROM type
Format file
Fig. K.6 (c) DATA LOADING DIRECTORY Screen (for ROM Cassette)
The type of mounted ROM cassette (ROM format file) is displayed (see the table
below). If the displayed ROM cassette type does not agree with that of the
connected ROM cassette, check the ROM cassette.
ROM cassette/ROM format file Description
1M-bit ROM without a sub-CPU P-CODE 256K (without sub-CPU)
2M-bit ROM without a sub- CPU P-CODE 512K (without sub-CPU)
1M-bit ROM with a sub-CPU P-CODE 256K (with sub-CPU)
2M-bit ROM with a sub-CPU P-CODE 512K (with sub-CPU)
CAUTION
If an alarm related to the memory card occurs or when
displaying memory card directories, confirm the title. When
the CNC unit has been activated with the cursor (² and ³)
keys pressed down, the title should read:
SYSTEM DATA LOADING (CASSETTE)
If this title is not displayed, activate the CNC unit again.
(6) The message ”OK? INPUT/CANCEL” appears. To register the
P-CODE file, press the input key. To not resister the P-CODE file,
press the ”cancel” key. Then the main menu [Fig. K.3 (b)] is then
displayed again.
(7) When the file has been successfully registered, the message
”PROGRAM COMPLETED” appears. Press the input key. The
main menu [Fig. K.3 (b)] is then displayed again.
