FAPT Macro Compiler (for PC) Programming manual Page 160

Programming manual
I. P–CODE LOADER FUNCTION
(FOR Series 16–B/C, 18–B/C,
21–TA, Series 16i/18i/21i–A/B)
B–66102E/10
APPENDIX
150
MACRO COMPILER/EXECUTER P-CODE LOADER
HEAD 1
(I/O PARAMETERS) (DATA TRANSFER)
ADRxxxxxxH:xx
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 0 ∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
BAUDRATE =11 ∗∗∗∗∗
STOP BIT = 1
INPUT CODE = 1
PUSH 1 KEY : RETURN TO HEAD SELECTION
(2) For the 21-TA
Once data has been loaded normally, the following screen appears.
Pressing the 1 key on this screen causes the P-CODE loader
processing to be terminated and the CNC to be started.
MACRO COMPILER/EXECUTER P-CODE LOADER
HEAD 1
(I/O PARAMETERS) (DATA TRANSFER)
ADRxxxxxxH:xx
I/O CHANNEL = 0 (MAPPING - 1MB)
I/O UNIT = 0 ∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
BAUDRATE =11 ∗∗∗∗∗
STOP BIT = 1
INPUT CODE = 1
PUSH 1 KEY : CNC START WITH EXECUTER
If an error occurs during loading, the following error message is
displayed.
To retry loading, press the 1 key. (The processing is repeated, starting
from RAM initialization.)
When you press CAN key and numeric ”1” key on the MDI keyboard, the
P-CODE loader processing is terminated and the CNC is started.
If a Series with two-path control is being used, the path selection screen
is displayed again.
