FAPT Macro Compiler (for PC) Programming manual Page 215

Programming manual
B–66102E/10
M. PARAMETERS
APPENDIX
205
IMG = 0 : 16-T type (Special G code)
= 1 : 16-G type (Special G code)
HRGC = 0 : 9I high resolusion monochrome CRT, standard
= 1 : 9I high resolution monochrome CRT, brightness
modulation mode setting (paint)
NOP_B = 0 : When no other address is specified in a block that calls
a subprogram by a T or M code, the block is executed.
= 1 : The block is not executed.
CUTLG = 0 : Does not count cutting distance
= 1 : Count cutting distance
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
9005 TMACC AXCLS AX4CL AX3CL AX2CL AX1CL
AX1CL = 0 : Macro program call by the 1st address is invalid
= 1 : Macro program call by the 1st address is valid
AX2CL = 0 : Macro program call by the 2nd address is invalid
= 1 : Macro program call by the 2nd address is valid
AX3CL = 0 : Macro program call by the 3rd address is invalid
= 1 : Macro program call by the 3rd address is valid
AX4CL = 0 : Macro program call by the 4th address is invalid
= 1 : Macro program call by the 4th address is valid
AXCLS = 0 : Always program O9009 is called irrespective of
specified axes.
= 1 : The program number to be called depends on a specified
axis:
Program O9031 is called when 1st axis is specified.
Program O9032 is called when 2nd axis is specified.
::
Program O9038 is called when 8th axis is specified.
TMACC= 0 : Macro call by T code is invalid
= 1 : Macro call by T code is valid
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
9006 NNUM US19W CNCHG DAUXR STDM KEYC DIOC
DIOC = 0 : Standard UI:G54/G55 and UO:F54/F55 are used for
UI/UO(#1000-#1132) of execution macro/
conversational macro.
= 1 : UI:G82/G83 and UO:F84/F85 are used for UI/UO
(#1000-#1132) of execution macro/ conversational macro.
KEYC = 0 : When KEY switch =0, completion code #8529=254 in an
access to NC program
= 1 : KEY switch is not cheched in an access to NC program
STDM = 0 : The mode and status display is changed on the USER-1,
USER-2, and USER-3 screens on which the
conversational macro screen is displayed.
= 1 : The mode and status display is left unchanged on the
USER-1, USER-2, and USER-3 screens on which the
conversational macro screen is displayed.
