FAPT Macro Compiler (for PC) Programming manual Page 213

Programming manual
B–66102E/10
M. PARAMETERS
APPENDIX
203
NOTE
Usually, undefined parameters need to be set to 0.
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
9000 M3MB M2MB M1MB M512 M256 M128
Compile
parameter
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
9001 M4MB
Compile
parameter
M4MB M3MB M2MB M1MB M512 M256 M128
4.0MB 1 0 0 0 0 0 0
3.0MB 0 1 0 0 0 0 0
2.0MB 0 0 1 0 0 0 0
1.0MB 0 0 0 1 0 0 0
512KB 0 0 0 0 1 0 0
256KB 0 0 0 0 0 1 0
128KB 0 0 0 0 0 0 1
NOTE
1 For the 21-TB (controller A), always specify 128 KB.
2 For the Series 16, a 128-KB ROM-format file cannot be
specified.
3 For the 21-MB or, 21-TB (controller B), no more than 1.0 MB
can be specified.
4 For the 0i–A, no more than 512 KB can be specified.
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
9002 EXT1 PWSR DAUX XDIL EVF ACL2 ACL1 TCAL
TCAL = 0 : Makes invalid the sub-program call with T code
= 1 : Makes effective the sub-program call with T code
ACL1 = 0 : Makes invalid call by the specific code
= 1 : Makes effective call by the specific code (O9004/#146)
ACL2 = 0 : Makes invalid call by the specific code
= 1 : Makes effective call by the specific code (O9005/#147)
EVF = 0 : Extension P-CODE variable #20000 is the floating
decimal point format
M.2
PARAMETERS
OTHER THAN
SERIES 15i
M.2.1
Compile Parameters
