FAPT Macro Compiler (for PC) Programming manual Page 199

Programming manual
B–66102E/10
L. NAME OF MACRO LIBRARY
APPENDIX
189
System name RemarksLibrary file nameSpecification
FANUC Series 18i–B
MACRO LIBRARIES
A08B–9001–J831#ZZ07 F18IMB_xx.MEX
F18ITB_xx.MEX
18TMMB_xx.MEX
18TMTB_xx.MEX
Series 18i–MB
Series 18i–MB
Series 18i–TMB (Sub side/M series)
Series 18i–TMB (Main side/T series)
MACRO LIBRARY
(16 P/L/W)
A08B–9001–J613#ZZ03 F16LA_xx.MEX
F16PA_xx.MEX
F16WA_xx.MEX
F16LB_xx.MEX
F16PB_xx.MEX
Series 16–LA
Series 16–PA
Series 16–WA
Series 16–LB
Series 16–PB
MACRO LIBRARY
(15A)
A08B–9001–J620#ZZ03 F15_A_xx.MEX
F15_B_xx.MEX
F15_C_xx.MEX
F15_D_xx.MEX
F15_E_xx.MEX
Series 15–A W/0 sub
Series 15–A with sub (Main side 256K
byte)
Series 15–A with sub (Sub side 256K
byte)
Series 15–A with sub (Main side 512K
byte)
Series 15–A with sub (Sub side 512K
byte)
MACRO LIBRARY
(15B)
A08B–9001–J640#ZZ03 F15B_Axx.MEX
F15B_Bxx.MEX
F15B_Cxx.MEX
F15B_Dxx.MEX
F15B_Exx.MEX
F15B_Fxx.MEX
Series 15–B W/O sub 256K byte
Series 15–B W/O sub 512K byte
Series 15–B with sub (Main side 256K
byte)
Series 15–B with sub (Sub side 256K
byte)
Series 15–B with sub (Main side 512K
byte)
Series 15–B with sub (Sub side 512K
byte)
FANUC Series 15i
MACRO LIBRARIES
A08B–9001–J640#ZZ07 F15IA_xx.MEX For Series 15i–MA
MACRO LIBRARY A08B–9001–J690#ZZ03 F20MA_xx.MEX Series 21–MB (D201 series)
(21MB)
F21MB_xx.MEX Series 21–MB (DDA1 series)
MACRO LIBRARY A08B–9001–J633#ZZ03 PMDT_xx.MEX Series 21–TA (8860 series)
(21TA)
F21TA_xx.MEX Series 21–TA (8865,8866 series)
MACRO LIBRARY
(21TB)
A08B–9001–J639#ZZ03 F21TB_xx.MEX Series 21–TB (controller A) (DE01 se-
ries)
F21TBN_xx.MEX Series 21–TB (controller B) (DEA1 se-
ries)
MACRO LIBRARY
(21TB)
A08B–9001–J639#ZZ03 F21LTB_xx.MEX Series 21–TB (loader control)
FANUC Series 21i–A
MACRO LIBRARIES
A08B–9001–J769#ZZ07 F21MI_xx.MEX
F21TI_xx.MEX
Series 21i–MA
Series 21i–TA
FANUC Series 21i–B
MACRO LIBRARIES
A08B–9001–J832#ZZ07 F21IMB_xx.MEX
F21ITB_xx.MEX
Series 21i–MB
Series 21i–TB
MACRO LIBRARY
(20F G)
A08B–9001–J670#ZZ03 DZ70_xx.MEX Series 20–FA (512K byte)
MACRO LIBRARY
(20F GP)
A08B–9001–J671#ZZ03 DZ71_xx.EE1
DZ71_xx.EE2
With Series 20–FA Guidance Program-
ming function (1M byte)
POC PRG.SRC
FACE PRG.SRC
DRILL PR.SRC
SIDE PRG.SRC
With Series 20–TA Guidance Program-
ming function
