CNC Setting Tool Operators manual Page 121

Operators manual
B-64174EN/01 PROFIBUS CONFIGURATION TOOL 4.FILE MANAGEMENT FUNCTION
- 111 -
Setting item
Item Description
Data file
designation
Set a data file to be newly created.
Name Set the name of a data file.
When making a modification to "Comment", do not
modify this item.
Comment Set a comment on a data file to be created.
An arbitrary comment (not longer than 249 characters)
can be entered on more than one line.
In the comment column of the list of files, the first line
of this field is displayed.
Button
Item Description
OK Validates operations on this screen and enables the
configuration tool to be started.
At this time, the configuration tool handles a newly
created data file.
Cancel Cancels operations on this screen and closes this
screen.
Previous page
Next page
