CNC Setting Tool Operators manual Page 173

Operators manual
B-64174EN/01-1
Title
Draw
No.
Ed. Date Design Description
Date 05.1.21 Design. T.Hosaka Apprv.
43/49
page
FANUC CNC Setting Tool
OPERATOR’S MANUAL
4.4.6 Get from Memory Card Screen
This subsection describes the Get from Memory Card screen.
This screen has function to get data file from the memory card.
The procedure to display the Get from Memory Card screen is described
below.
Please see the manual of CNC to get detailed information about how to
punch parameters to the memory card at CNC.
1 Insert the memory card, which parameters have been written to, to the
memory card device on the personal computer.
2 Select and right-click <MachineA>¥<CNC Setting Tool> in the tree then
choose [Get from Memory Card].
3 Directory of memory card screen is displayed. Select the drive and
directory of memory card, and then push OK button. (Specified settings
are saved.)
