FANUC CNC Setting Tool
OPERATOR’S MANUAL
Related manuals
The table below lists manuals related to this manual.
When using this manual, refer to the manuals listed below as well.
Related manuals of FANUC Series 30i/300i, 31i/310i, 32i/320i -A
Manual name
Specification
number
DESCRIPTIONS B-63942EN
CONNECTION MANUAL (HARDWARE) B-63943EN
CONNECTION MANUAL (FUNCTION) B-63943EN-1
USER’S MANUAL (Common to T series/M
series)
B-63944EN
USER’S MANUAL (T series) B-63944EN-1
USER’S MANUAL (M series) B-63944EN-2
MAINTENANCE MANUAL B-63945EN
PARAMETER MANUAL B-63950EN
License agreement
The terms and conditions set forth by FANUC must be agreed upon by a
costumer who purchases the CNC setting tool.
This is an Agreement between you and FANUC LTD ("FANUC") regarding
the Software Product ("the Software") which you receive with this
Agreement.
1.GRANT OF LICENSE
FANUC grants you the following right regarding the Software:
(1) You may use the Software on a single computer.
(2) In case you will use the Software upon the plural number of computers,
the same number of license to use the Software as that of the computers
on which you will use the Software shall be required even though you
will not use the Software simultaneously.
(3) In case you will use the Software by loading it into temporary
memories of plural number of computers through the network, the same
number of license to use the Software as that of the computers on which
you will use the Software shall be required.
(4) You may make one copy of the Software solely for backup or archival
purposes.
2.COPYRIGHT
Copyright of the Software is owned by FANUC. Therefore, you may not
copy the Software except for the usage granted in Article 1 (GRANT OF
LICENSE).
Previous page
Next page
