CNC Setting Tool Operators manual Page 136

Operators manual
B-64174EN/01-1
Title
Draw
No.
Ed. Date Design Description
Date 05.1.21 Design. T.Hosaka Apprv.
6/49
page
FANUC CNC Setting Tool
OPERATOR’S MANUAL
The parameter file extracted partly from the contents of CNC output is not
supported by this tool.
Parameter information displayed on the screen
Parameter information that is displayed on the screen is based on the
manuals shown below.
Manual name Japanese English
FANUC Series 30i-MODEL A CONNECTION MANUAL
(FUNCTION)
B-63943JA-1/02 B-63943EN-1/02
FANUC Series 30i-MODEL A PARAMETER MANUAL B-63950JA/02 B-63950EN/02
FANUC AC SERVO MOTOR PARAMETER MANUAL B-65270JA/04 B-65270EN/04
FANUC AC SPINDLE MOTOR PARAMETER MANUAL B-65280JA/04 B-65280EN/04
FANUC MANUAL GUIDE i OPERATOR’S MANUAL B-63874JA/05 B-63874EN/05
NOTE
About Spindle, parameters for main spindle of alpha i
series are supported. Parameters for sub spindle are not
supported.
Explanation of Terms
Parameter File
It is a file to which the parameters got from CNC are saved. It is transmitted
to CNC via Ethernet and Memory Card.
This tool handles Parameter File as the following two types; Edit File and
Master File.
Edit File
The value of Edit File is displayed in the screen. User can change it.
Master File
The value of Master File is displayed on the screen. It is a base file of
comparison. It is not allowed to change the value of a parameter file opened
as a Master File.
NOTE
In both Master File and Edit File, the following system
configuration has to be the same.
- Number of Machine Group
- Number of Path
- Number of Spindle
- Number of Servo Axis
If some of them are different, you can not open it as a
Master File.
