CNC Setting Tool Operators manual Page 98

Operators manual
3.OPERATION PROFIBUS CONFIGURATION TOOL B-64174EN/01
- 88 -
Button on the Change Grouped Slots screen (slave selection)
Item Description
Select Displays the Change Grouped Slots screen
(modification) for a selected slave station.
Close Closes this screen.
Display item on the Change Grouped Slots screen (modification)
Item Description
Slave Station No. Displays the slave station number of the slave
station.
Number of
Grouped Slots
Displays the number of grouped slots of the slave
station.
Slave Information Displays slave information about the slave station.
Vendor Name Displays a vendor (manufacturer) name.
Model Name Displays a model name.
Ident No. Displays a model identification number (PROFIBUS
ID).
Number of
Slots
Displays the total number of slots currently set.
This number matches the number of modules added
to "Added Module List" on the Add Module screen.
DI/DO Size Displays the total DI/DO size (in bytes) of the
modules currently set.
Total Slots
Information
Displays the slot information of all slave stations.
Total Grouped
Slots
Displays the total number of grouped slots of all
slave stations.
Total Slots Displays the total number of connection slots of all
slave stations.
Available Modules Displays a list of grouped slots and modules
currently set.
Grouped Slot Grouped slot number to which each module
belongs.
When the same grouped slot number is applicable,
"- - -" is displayed.
Slot Connection slot number
Module Name Name of a module currently set
I/O Type I/O type
One of the types indicated below is displayed.
When "I" or "O" is displayed, an input size or output
size is indicated (in bytes).
"- - -" : State where no module is set
(Equivalent to Module Length = 0)
"I / -" : Input module
"- / O" : Output module
"I / O" : Input/output module
"- / -" : Non-input/non-output module
(Equivalent to Module Length = 1 and
Module Data = 0)
"OVR" : When the total of an input size and output
size is greater than 244 bytes
"ERR" : When module data does not meet the
PROFIBUS standard
