CNC Setting Tool Operators manual Page 160

Operators manual
B-64174EN/01-1
Title
Draw
No.
Ed. Date Design Description
Date 05.1.21 Design. T.Hosaka Apprv.
30/49
page
FANUC CNC Setting Tool
OPERATOR’S MANUAL
Display item
Item Description
Configuration
tree
Settings are displayed in tree form.
In the example below, <Machine_A>
represents the type/machine name of a
registered CNC, and <CNC Setting Tool>
represents the name of a usable
configuration tool.
The type/machine name of a registered CNC
is hereinafter referred to as
<(registered-CNC-name)>.
File list When a configuration tool is selected, a list of
data files handled by the configuration tool is
displayed.
Menu
Item Description
Machine
Type...
Displays the Machine Property
screen if <Type/Machine name> is
selected in the configuration tree.
File
Exit Quits the file management function.
Displays the Machine Property
screen for
<(registered-CNC-name)> when
selected in the configuration tree.
Modify...
Displays the configuration tool for a
data file when selected from the list
of files.
Deletes all data of
<(registered-CNC-name)> when
selected in the configuration tree.
Delete...
Deletes a data file when selected
from the list of files.
Displays The Machine name input
screen when
<(registered-CNC-name)> is
selected in the configuration tree.
And then copies the type/machine
name.
Copy...
Makes a preparation for copying a
data file when selected from the list
of files.
Edit
Cut... Makes a preparation for cutting a
data file when selected from the list
of files.
